weight 27,900 kg, Board Thickness 1.2-7.0 mm, Production Speed 17.5-400 blanks/min, Maximum Sheet Size 1700 × 600 mm, Maximum Skip Feed Size 1700 × 800 mm, Minimum Sheet Size 300 × 175 mm (560 × 250 mm with down-stacker), Maximum Print Area 600 × 1700 mm, Print Cylinder Diameter 218.3 mm (nominal), Power Requirements 105 kVA (80 kVA typical); 49 kW DC main drive, Air Requirements 300 dm³/min @ 500–600 kPa, Total Weight 27,900 kg – Feed Unit: 3,100 kg, Print Units: 2,100 kg, Slotting Unit: 4,200 kg, Die Cutting Unit: 2,700 kg, Folding Unit: 5,700 kg
